Rendering in Unreal Engine 5

A shot exported to OpenUSD for Blender Cycles can also be rendered with Unreal Engine 5.8: the same USD, imported with Unreal's USD Stage importer and rendered with Lumen, hardware ray tracing and Movie Render Queue. A 108 frame take renders in about 5 minutes including the import (0.13 to 0.23 s a frame, against 6.9 to 8.5 s a frame in Cycles), and the cinematic preset adds temporal accumulation, depth of field and a film look. How the two renderers share the export is described in One city, three renderers.

This guide installs the engine, prepares the project and the material sets, renders t7ArchSoffit (the shot of the Cycles guide), gives the measured times and lists the known limits. The commands are written for a Linux shell.

What you need

Item	Requirement
Operating system	Linux x86-64; the takes below were rendered on Ubuntu 22.04
GPU	an NVIDIA RTX GPU with the proprietary driver and Vulkan (tested on RTX 6000 Ada, 48 GB, driver 580)
Engine	Unreal Engine 5.8 (tested with 5.8.3 built from source)
Disk	about 200 GB for the engine built from source (197 GB measured); the take's harvest and USD as in the Cycles guide
Export tools	a source checkout with the client, Playwright's Chromium, Python 3.8 or later and uv, as in the Cycles guide
Assets	the street tree set Blender/bxtrees2 from the dataset, and the CC0 material sets (below)

Get Unreal Engine 5.8

The engine is licensed by Epic Games under the Unreal Engine End User License Agreement (https://www.unrealengine.com/eula). Linking accounts and accepting the agreement are steps you take yourself, under your own Epic Games account.

Linux, from source. Epic publishes the source in the private EpicGames/UnrealEngine repository on GitHub. To get access, sign in at epicgames.com, link your GitHub account under your account's apps and accounts settings, accept the licence agreement there, and accept the invitation to the EpicGames organisation that GitHub then sends. Then:

git clone --depth 1 --branch 5.8.3-release https://github.com/EpicGames/UnrealEngine.git UE_5.8
cd UE_5.8
./Setup.sh
./GenerateProjectFiles.sh
make UnrealEditor
for t in ShaderCompileWorker UnrealPak CrashReportClient InterchangeWorker; do make $t; done
export UE_ROOT=$PWD

Setup.sh downloads the engine's binary dependencies. The editor target builds every engine plugin, including the ones the project needs (USD importer, Movie Render Queue, Python scripting, editor and sequencer scripting), so the project has no build of its own. The helper targets are built one at a time because the build tool runs one instance per engine. On a machine with 128 hardware threads the editor build took 16 minutes.

Windows, from the launcher. The Epic Games Launcher installs a binary build: Unreal Engine, Library, Engine Versions, add version 5.8. Set UE_ROOT to the installed engine folder. ue_take.py starts the editor from Engine/Binaries/Win64 on Windows and from Engine/Binaries/Linux elsewhere. The take scripts have been tested on Linux only; on Windows the engine renders with Direct3D 12 instead of Vulkan, so expect small differences and report problems.

The project

client/tools/ar34/export/ue_project/ is the Unreal project the takes use:

File	Contents
BoundlessUE.uproject	the plugins: USD importer, Movie Render Pipeline, Python script plugin, editor scripting utilities, sequencer scripting
Config/DefaultEngine.ini	Lumen, Nanite, virtual shadow maps, MegaLights for the street lamps, hardware ray tracing on Vulkan SM6
Python/ue_masters.py	the master materials, one per material family of the export, as Custom HLSL nodes, built into /Game/Bx/ on the first import
Python/ue_foliage.py	the masters of the tree set: geometry leaves, alpha-tested leaf cards and bark

Content/, Saved/, Intermediate/ and DerivedDataCache/ are generated and kept out of git. Nothing in the project needs to be opened by hand: ue_take.py runs the editor in its command line mode for the import and the engine in -game mode for the render. Set these variables in every shell you use below:

export UE_ROOT=~/UE_5.8                 # the engine
export BXUE_DDC=~/bx/ue_ddc             # a writable folder for the engine's local derived data cache
export BXTREES_ASSETS=$PWD/.cache/hf/Blender/bxtrees2

The tree set comes from the dataset, as in the Cycles guide:

hf download mehmetkeremturkcan/valdrada --repo-type dataset --revision v0.3.1 --include "Blender/bxtrees2/*" --local-dir .cache/hf

Fetch the CC0 material sets

Unreal draws the asphalt, the sidewalks, the kerbs, the walls by material and the viaducts' steel with 13 CC0 material sets from Poly Haven at 4K, layered over the export's own materials. tools/assets/fetch_hq.py downloads them (371 MB) and writes hq.json, which records for each set its source page, licence, real size in metres, files and mean albedo:

uv run --no-project --with pillow --with numpy python tools/assets/fetch_hq.py --out ~/bx/hq

Then point the takes at the sets with export BXUE_HQ=~/bx/hq/hq.json (otherwise "manifest" under "hq" in client/tools/ar34/export/ue_families.json is used, which names the folder of the development machine). That table maps each pbrLib set, ground kind, viaduct layer and facade wall class to its set. A take rendered without the sets, or with BXUE_NOHQ=1, uses the export's own textures.

Export the shot

The Unreal take renders the USD that the Cycles guide writes. Follow its sections Capture the shot and Write the USD, with BXTREES_ASSETS set as above, so that ~/bx/u/t7ArchSoffit.usda exists. A USD already rendered with Cycles needs no new export.

Render the take

python3 client/tools/ar34/export/ue_take.py --usd ~/bx/u/t7ArchSoffit.usda \
    --outdir ~/bx/ue/t7ArchSoffit --work ~/bx/ue_work/t7ArchSoffit --res 2560x1440 --gpu 0

The script runs three stages, each in its own process:

1. Prep. ue_prep.py writes the take's Unreal layer: the per-vertex data packed into UV sets, the moving vehicles, trains and signal lenses as animated transforms, and ue_t7ArchSoffit.json with the materials' tags.
2. Import. UnrealEditor-Cmd builds the master materials when they are missing, imports the stage into /Game/Takes/t7ArchSoffit/ (Nanite meshes, actors, the camera and the moving sets as Level Sequence tracks), makes each tagged material an instance of its family's master, sets up the sun, the sky, the street and vehicle lamps and the film look, and writes the Movie Render Queue job. A fingerprint of the take's layers is kept beside the import, so rendering the same USD again reuses it (--reimport imports it again).
3. Render. The engine renders the frames off screen into ~/bx/ue/t7ArchSoffit/frame_%05d.jpg, with the planar depth in _depth/ and the regions of the data pass in _ue/regions/. take_ue.json in the same folder records the times of every stage; the logs of the stages (prep.log, import.log, render.log) are in the work folder.

--gpu picks the Vulkan device. Existing frames are kept unless --overwrite is given. --light web replaces the physical light (the default, shared with Cycles through phys_light.json) by the rig calibrated against the web takes, and --treewind 0 freezes the trees' wind.

The cinematic preset. --cine renders 8 temporal samples per frame over a 180 degree shutter centred on the frame, with depth of field on the subject at f/2.8 (--fstop), the client's bloom, film grain (--grain), a deeper vignette, light volumetric fog by day (--fog) and the analytic haze at night:

python3 client/tools/ar34/export/ue_take.py --usd ~/bx/u/t7ArchSoffit.usda \
    --outdir ~/bx/ue/t7ArchSoffit --work ~/bx/ue_work/t7ArchSoffit --res 2560x1440 --gpu 0 --cine
ffmpeg -framerate 30 -i ~/bx/ue/t7ArchSoffit/frame_%05d.jpg -c:v libx264 -crf 16 -pix_fmt yuv420p ~/bx/t7ArchSoffit_ue.mp4

Batches. bx_render_all.mjs renders a list of shots with Unreal and the same checks as the Cycles takes. It writes the harvest and the USD when a shot has none, or reuses a Cycles batch's with --usdfrom <work dir>:

node client/tools/ar34/export/bx_render_all.mjs --target ue --shots t7ArchSoffit --gpus 0 \
    --work ~/bx/ue_batch --clips ~/bx/ue_takes --nopreview --nocut --uetake " --cine"

The value of --uetake (extra ue_take.py options) begins with a space so that it is not read as an option of the batch. --cycref <dir> names the root of physical Cycles takes of the same shots, which ue_check.py then compares region by region. After the summary the batch prints the coverage report of every shot's USD.

Times

Measured on RTX 6000 Ada GPUs at 2560 × 1440, 108 frame takes with the bxtrees2 trees:

Stage	Default	Cinematic (--cine)
Prep	9 to 20 s	9 to 20 s
Import, first time	146 to 389 s	146 to 389 s
Import, the same USD again	40 to 95 s	40 to 95 s
Render, per frame	0.13 to 0.23 s	1.05 to 1.25 s
Whole take	4.7 to 5.6 min	5.5 to 13 min

For t7ArchSoffit with --cine: prep 20 s, import 364 s, the render 178 s (the first frame 43 s with the engine start and 48 warm-up frames, then a median of 1.14 s a frame) and 67 s to write the frames. The first take on a machine also compiles the engine's global shaders and builds the tree set's Nanite meshes (about 4.5 minutes); the derived data cache keeps both. For comparison, the physical light Cycles takes of the same shots needed 6.9 to 8.5 s a frame.

Known limits

Limit	Detail
Contiguous takes	Render a take's frames as one range. A render that jumped from frame 0 to frame 54 has hung the GPU, so final batches use --nopreview, whose three preview frames are not contiguous.
Walkers and wind outside ray tracing	The walkers' skinned meshes are left out of the ray tracing scene and the trees' wind is not evaluated for ray tracing: Lumen lights and reflects the scene without the walkers (the sun's shadow maps still cast their shadows) and sees the crowns at rest. Both changes, with async compute off, stopped a GPU hang during takes. BXUE_RTDYN=1 restores them, for tests.
Sign lights	At night the lit signs and shop interiors light their surroundings as rect lights. One shot lost the GPU device three times with them and was rendered with BXUE_EMITK=0, which turns them off.
Linux only	See Get Unreal Engine 5.8.

Credits in films

A film rendered with Unreal Engine that has credits must carry the notices of the Unreal Engine End User License Agreement in its credits, with the film's title and the current year:

<Title> uses Unreal® Engine. Unreal® is a trademark or registered trademark of Epic Games, Inc. in the United States
of America and elsewhere.
Unreal® Engine, Copyright 1998 – 2026, Epic Games, Inc. All rights reserved.

Common problems

Problem	Fix
The render exits at once with Vulkan errors in render.log	Install the NVIDIA driver's Vulkan component; ue_take.py selects NVIDIA's Vulkan driver when /usr/share/vulkan/icd.d/nvidia_icd.json exists.
core option ... missing in this engine	The engine is not 5.8: the import refuses an engine whose USD importer or Movie Render Queue lacks an option the take needs.
Materials render flat or white	The masters were not built: look for [bxue] errors in import.log in the work folder.
Plain asphalt and walls	The CC0 sets were not fetched, or neither BXUE_HQ nor hq.manifest in ue_families.json points to hq.json.
The trees are the client's	BXTREES_ASSETS was not set when the USD was written.
